Purpose
Applicable to a variety of multiple strand copper wires, strands of wire, multiple strand wire especially for large section multiple strand insulation wire cable and high iron cable into cable unexpected performance characteristics.
Performance Characteristics
Technical Data
| Model | DJ-XB-1000 | DJ-XB-1250 | DJ-XB-1600 | DJ-XB-2200 | |
| Pay-off bobbin | Ф500-ф630-ф800 | Ф500-ф630-ф800 | Ф1000-ф1250 | Ф1000-ф1250 | |
| Take-up bobbin | Ф1000 | Ф1250 | Ф1600 | Ф2200 | |
| Outer diameter | Ф1.0-Ф6.0 | Ф1.0-Ф6.0 | Ф3.0-Ф10.0 | Ф3.0-Ф10.0 | |
| Max twisting diameter | Ф25 | Ф30 | Ф35 | Ф40 | |
| Lay | 30mm-300mmStepless regulation | 30mm-300mmStepless regulation | 100mm-700mmStepless regulation | 100mm-700mmStepless regulation | |
| Speed of rotation | 500 | 400 | 330 | 300 | |
| Wire arrangement direction | Bobbin reciprocates on the screw rod | ||||
| direction | Left to right or Right to left | ||||
| Taping method | Center winding or side straightening | ||||
